Eco-friendly 3.7V LIR14500 Primary Lithium Battery 600mAh With PCB

Eco-friendly 3.7V LIR14500 Primary Lithium Battery 600mAh With PCB

Eco-friendly 3.7V LIR14500 Primary Lithium Battery 600mAh With PCB

Product Details:

Place of Origin: China
Brand Name: MAXPOWER
Certification: CE,ROHS, UL
Model Number: MP- 14500 600mAh 3.7 V

Payment & Shipping Terms:

Minimum Order Quantity: 100 PCS
Price: Negotiable
Packaging Details: white / gift box/ blister card
Delivery Time: 15 days
Payment Terms: L/C, T/T
Supply Ability: 3, 000, 000PCS
Contact Now
Detailed Product Description





3.7V LIR14500 Lithium ion Cylindrical Battery Of 600mAh With PCB





Quick Detail:



1. Nominal Voltage: 3.7V

2. Rated Capacity: 600mAh

3,There is a PCB on the Negative Pole



Specification:





No.

Item

General Parameter

Remark

1

Rated Capacity

Typical

600mAh

Standard discharge(0.2C5A) after Standard charge

Minimum

580mAh

2

Nominal Voltage

3.7V

Mean Operation Voltage

3

Voltage at end of

Discharge

3.0V

Discharge Cut-off Voltage

4

Charging Voltage

4.2V



5

Internal Impedance

≤80mΩ

Internal resistance measured at AC 1KHZ after 50% charge

The measure must uses the new batteries that within one week after shipment and cycles less than 5 times

6

Standard charge

Constant Current 0.2C5A

Constant Voltage 4.2V

0.01 C5A cut-off



7

Standard discharge

Constant current 0.2C5A

end voltage 3.0V



8

Fast charge

Constant Current 1.0C5A

Constant Voltage 4.2V

0.01 C5A cut-off



9

Fast discharge

Constant current 1.0C5A

end voltage 3.0V



10

Maximum Continuous Charge Current

1.0 C5A



11

Maximum Continuous Discharge Current

1.5 C5A



12

Operation Temperature Range

Charge: 0~45℃

60±25%R.H.

Bare Cell





Discharge: -10~60℃



13

Storage Temperature Range

Less than 1 year: -20~25℃

60±25%R.H.

at the shipment state





less than 3 months: -20~40℃







Less than 7 day : -20~65℃



14

Cell  Dimension

High:49.5±0.5 mm

Initial  Dimension





Diameter: 14.0±0.5 mm
