| Place of Origin: | China |
| Brand Name: | MAXPOWER |
| Certification: | IEC62133,UN38.3,CE,ROHS,UL,REACH |
| Model Number: | - 652030 240 mAh 3.7V |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | TRAY / Blister packing |
| Delivery Time: | 20-30 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 2, 000, 000PCS |
| High Light: | ultra thin lithium polymer battery,high power lipo battery |
||
|---|---|---|---|
20C Discharge 240mAh 3.7V li-ion rechargeable battery for Electronic toys
Quick Detail:
1.Nominal Capacity: 240mAh
2.Nominal Voltage: 3.7V
3.Size: 6.5*20*30mm (Thickness*Width*Length)
4.High discharge: 20C Peak discharge and 5C continuous discharge
5.1000 cycle life
6.Certificate: IEC62133,CE,UL,UN38.3,REACH
7.Abbreviations: Li-polymer,LiPO,Li-poly,PLI,Li-pol,LIP or LiP battery
8.Discharge cut-off voltage: 3.0V
Description:
Withstand 20C peak discharge for 10 seconds
High storage characteristics,Long cycle life
Light weight,coact size,High energy density
High voltage which is three times of NiMH or NiCd
High discharge platform
Can be fast charged with exclusive Lithium ion battery charger under CC-CV mode.
High safety which passed UL-164
Low self-discharge rate with 10% fading per month
Applications:
R/C Application,R/C Helicopter,R/C Toys,Blue tooth device,headphones,PDAs,3 / 4 player,digital cameras,digital camcorders,Medical devices,Eyeglass,Portable DVD,GPS Tracking,E-book,Notebook PC,Ipad, Net book,Tablet PC,Electronic toys etc.
Specifications:
|
Bitmap |
MAXPOWER INDUSTRIAL CO.LTD |
|
- Lithium Polymer battery specification |
|
|
Model |
- 652030 240mAh 3.7V |
|
Dimension |
6.5*20*30 MM (Thickness*Width*Length) |
|
Voltage |
3.7 V |
|
Capacity |
240 mAh |
|
Iedance |
<150 mΩ |
|
Discharge cut-off voltage |
3.0V |
|
Maximum Charge voltage |
4.2V |
|
Standard charge current |
0.2C |
|
Standard discharge current |
0.2C |
|
Approx Weight |
7g |
|
Working teerature |
Charge:0-45 C.degree |
|
Discharge:-20-60 C.degree |
|
|
Storage teerature |
minus 20 - 45 degree |
|
Normal teerature capacity |
240mAh |
|
Cycle life |
1000 cycles |
Coetitive Advantage:
Professional Sales Team
Excellent post-sales service
Coetitive factory price
One year warranty
Quick delivery as per customer requirement
Communication with customers
A: Does Lithium Polymer battery have memory effect?
B: No memory effect.
A: what is the cycle life for the Lithium Polymer battery?
B: Cycle life is the number of charge and discharge cycles a battery can achieve
Before the discharged capacity drops to end of life, our Lithium Polymer battery cycle life can reach 1000 cycles
A: What is the post-sales service?
B: We provide one year quality warranty after delivery and 0.1% spare parts.
A: How do you deliver the battery?
B: We can do sea or air shipment for storage battery with authorized MSDS and Guarantee Letter. They are usually 30% pre-recharged before shipment.
