3350mAh 3.7 18650 Volt Lithium Ion Battery 6.5A Discharge Power Cell
3350mAh 3.7 18650 Volt Lithium Ion Battery 6.5A Discharge Power Cell
Basic Properties
Place of Origin:
China
Brand Name:
MaxPower/OEM/China TOP brand
Certification:
CE UL CB UN38.3 MSDS IEC ENC BIS
Model Number:
18650 3350mAh
Trading Properties
Minimum Order Quantity:
1000PKS
Price:
Negotiation
Product Summary
3350mAh 3.7 Volt Lithium Ion Battery 6.5A Discharge Power Cell 18650 3350mAh 3.7V Rechargeable cylindrical Lithium Ion Batteries 3.7V CE BIS IEC2133 CB UL Lithium Ion Battery 18650 3350mAh 3.7V (series models are as below) power cell for vacuum cleaner vacumm robot 3C discharge Normal type Li-ion ...
Product Custom Attributes
Highlight
3.7 Volt Lithium Ion Battery
,3350mAh 3.7 Volt Lithium Ion Battery
,3350mAh 18650 Lithium Battery
Battery Type:
Li-ion Cell
Capacity:
3350mAh
Voltage:
3.7V
Weight:
49g
Guarantee:
One Year
Life Cycle:
1000 Cycles
Internal Resistance:
≤60 MΩ(with PTC、CID)
Size:
D18.6mm*H65.3mm
Product Description
Detailed Specifications & Features
3350mAh 3.7 Volt Lithium Ion Battery 6.5A Discharge Power Cell
18650 3350mAh 3.7V Rechargeable cylindrical Lithium Ion Batteries 3.7V CE BIS IEC2133 CB UL
- Lithium Ion Battery 18650 3350mAh 3.7V (series models are as below)
- power cell for vacuum cleaner vacumm robot 3C discharge
- Normal type Li-ion Cell or High Rate 3C 5C 10C 12Cwith customer design
- MaxPower brand or OEM brand is ok
- Accept the trial order around 1K with courier door to door service
- UL CE ROSH KC IEC62133 CCC UN38.3 MSDS BIS certification is aviliable for many li-ion battery models
- Original China top brand 18650 cells for power tools.
- We accept the Customized battery pack and design OEM and ODM project .
Specification of the 18650 3350mAh battery:
| 1 | Capacity | Nominal Capacity:3350mAh (discharge with 0.2C to 2.5V) |
| Minimum Capacity:3250mAh (discharge with 0.2C to 2.5V) | ||
| 2 | Nominal Voltage | 3.6 V |
| 3 | Internal Iedance(AC 1KHZ) | ≤ 60mΩ |
| 4 | Standard Charge | Constant Current: 0.3C (975mA) |
| Constant Voltage: 4.2V | ||
| End Current: 50mA | ||
| 5 | Max. Charge Voltage | 4.2±0.05V |
| 6 | Max. Charge Current | 0.5C (1625mA) |
| 7 | Standard Discharge | Constant Current: 0.2C (650mA) |
| End Voltage: 2.5V | ||
| 8 | Max. Discharge Current | -20~5℃: 0.5C (1625mA) |
| 5~50℃: 1.5C (4875mA) | ||
| 9 | Max. Pulse Discharge Current | 2C (6500mA) |
| 10 | Operating Teerature | Charge:0 ~ 45℃ |
| Discharge:-20 ~ 50℃ | ||
| 11 | Storage Teerature | within one month: -20 ~ 50℃ |
| within three months: -20~ 45℃ | ||
| within one year: 0~45℃ | ||
| 12 | Weight Max. | 49.0 g |
| 13 | Max. Dimension | Diameter (φ): 18.6mm |
| Height (H) : 65.3mm |
More pics.
Application :
vacuum cleaner, vacuum robot, Torches , Flash light ,power tools , LED light , Emergency lighting, Toys ,
Robot ,Medical device ,sweeper , E-Bike , electric toothbrush,Consumer devices ETC.
POWER CELL(high rate for power tools)
| No. | Type | Models | Capacity (mAh) | Nominal Voltage (V) | Iedance(mΩ) | cut off voltage(V) | Max.Continuous Discharge Current | Cycle life | Operating Teerature |
| 1 | 14500 | 14500 | 850 | 3.6 | ≤70 | 2.75 | 1.7A(2C) | above 300 | -20~60 |
| 2 | 18650 | 18650P | 2000 | 3.6 | ≤20 | 2.75 | 20.0A(10C) | above 300 | -20~60 |
| 3 | 18650T | 2000 | 3.6 | ≤40 | 2.75 | 6.6A(3C) | above 500 | -40~90 | |
| 4 | 18650P5 | 2200 | 3.6 | ≤20 | 2.75 | 11.0A(5C) | above 5300 | -20~75 | |
| 5 | 18650P8 | 2500 | 3.6 | ≤18 | 2.5 | 30A(12C) | above 250 | -20~80 | |
| 6 | 18650M6 | 2600 | 3.6 | ≤35 | 2.75 | 7.5A(3C) | above 1000 | -20~60 | |
| 7 | 18650M7 | 2600 | 3.6 | ≤30 | 2.75 | 7.5A(3C) | above 1000 | -20~60 | |
| 8 | 18650P9 | 2900 | 3.6 | ≤40 | 2.5 | 8.7A(3C) | above 1000 | -20~60 | |
| 9 | 18650M9 | 3200 | 3.6 | ≤40 | 2.5 | 9.3A(3C) | above 1000 | -20~60 | |
| 10 | 21700 | 21700F2E | 5000 | 3.62 | ≤25 | 2.5 | 14.4A(3C) | above 1000 |
-20~60 |
Energy Cell:
| No. | Type | Models | Capacity (mAh) | Nominal Voltage (V) | Iedance(mΩ) | cut off voltage(V) | Max.Continuous Discharge Current | Cycle life | Operating Teerature |
| 1 | 18650 | 18650F56 | 2200 | 3.7 | ≤60 | 3 | 2.2A(1C) | above 300 | -20~60 |
| 2 | 18650R8 | 2600 | 3.7 | ≤60 | 3 | 2.6A(1C) | above 300 | -20~60 | |
| 3 | 18650F30 | 3000 | 3.7 | ≤60 | 3 | 4.5A(1.5C) | above 300 | -20~50 | |
| 4 | 18650L9 | 3350 | 3.6 | ≤60 | 2.5 | 4.8A(1.5C) | above 300 | -20~50 | |
| 5 | 21700 | 21700F2 | 5000 | 3.62 | ≤40 | 2.5 | 7.5A(1.5C) | above 300 | -20~50 |
Hot saling model:
| models | capactity | models | capactity | note |
| 18650 | 1200mAh | 18350 | 700mah | |
| 18650 | 1300mAh | 36600 | 7500mah | (militery use) |
| 18650 | 1500mAh | 32600 | 5000mah | (militery use) |
| 18650 | 1800mAh | 18500 | 1900mah | |
| 18650 | 2000mAh | 18500 | 1200mah | |
| 18650 | 2200mAh | 16310 | 850mah | |
| 18650 | 2500mAh | 10840 | 650mah | |
| 18650 | 2600mAh | 16650 | 1600mah | |
| 18650 | 3400mah | 14650 | 1000mah |
Regular saling models:
| No. | Type | Models | Capacity (mAh) | Nominal Voltage (V) | diameter ±0.05(mm) | Height ±0.5(mm) | |
| 1 | Lithium Cylindrical | 13490 | 650 | 3.7 | 12.9 | 48.5 | |
| 2 | Lithium Cylindrical | 14430 | 650 | 3.7 | 13.9 | 42.5 | |
| 3 | Lithium Cylindrical | 14500 | 700 | 3.7 | 13.9 | 64.5 | |
| 4 | Lithium Cylindrical | 14650 | 800 | 3.7 | 13.9 | 64.5 | |
| 5 | Lithium Cylindrical | 14650 | 1100 | 3.7 | 13.9 | 64.5 | |
| 6 | Lithium Cylindrical | 17280 | 600 | 3.7 | 16.65 | 27.5 | |
| 7 | Lithium Cylindrical | 17335 | 750 | 3.7 | 16.65 | 33.5 | |
| 8 | Lithium Cylindrical | 17500 | 1100 | 3.7 | 16.65 | 48.5 | |
| 9 | Lithium Cylindrical | 17650 | 1200 | 3.7 | 16.65 | 64.5 | |
| 10 | Lithium Cylindrical | 17650 | 1600 | 3.7 | 16.65 | 64.5 | |
| 11 | Lithium Cylindrical | 18490 | 1200 | 3.7 | 18.05 | 48.5 | |
| 12 | Lithium Cylindrical | 18490 | 1400 | 3.7 | 18.05 | 64.5 | |
| 13 | Lithium Cylindrical | 18650 | 1400 | 3.7 | 18.05 | 64.5 | |
| 14 | Lithium Cylindrical | 18650 | 1800 | 3.7 | 18.05 | 64.5 | |
| 15 | Lithium Cylindrical | 18650 | 2000 | 3.7 | 18.05 | 64.5 | |
| 16 | Lithium Cylindrical | 18650 | 2200 | 3.7 | 18.05 | 64.5 | |
| 17 | Lithium Cylindrical | 18650 | 2600 | 3.7 | 18.05 | 65.5 | |
| 18 | Lithium Cylindrical | 18740 | 1600 | 3.7 | 18.05 | 71.5 | |
| 19 | Lithium Cylindrical | 21750 | 3200 | 3.7 | 21.5 | 74.5 | |
| 20 | Lithium Cylindrical | 22430 | 2000 | 3.7 | 22.05 | 42.5 | |
| 21 | Lithium Cylindrical | 26650 | 3000 | 3.7 | 26.05 | 64.5 | |
| High Rate Series Li-ion 18650 re-chargeable battery | |||||||
| No. | Type | Models | Capacity (mAh) | Nominal Voltage (V) | diameter ±0.05(mm) | Height ±0.5(mm) | Discharge Rate(10C) |
| 1 | Lithium Cylindrical | 18650P-1100 | 1100 | 3.7 | 18.05 | 64.5 | 10C 15C 20C |
| 2 | Lithium Cylindrical | 18650P-1200 | 1200 | 3.7 | 18.05 | 64.5 | 10C 15C 20C |
| 3 | Lithium Cylindrical | 18650P-1300 | 1300 | 3.7 | 18.05 | 64.5 | 10C 15C 20C |
| 4 | Lithium Cylindrical | 18650CP-1400 | 1400 | 3.7 | 18.05 | 64.5 | 10C 15C 20C |
| 5 | Lithium Cylindrical | 18650CP-1500 | 1500 | 3.7 | 18.05 | 64.5 | 10C 15C 20C |
| 6 | Lithium Cylindrical | 18650CP-1600 | 1600 | 3.7 | 18.05 | 64.5 | 10C 15C 20C |
| 7 | Lithium Cylindrical | 18650CP-1700 | 1700 | 3.7 | 18.05 | 64.5 | 10C 15C 20C |
| 8 | Lithium Cylindrical | 18650CP-1800 | 1800 | 3.7 | 18.05 | 64.5 | 10C 15C 20C |
| 9 | Lithium Cylindrical | 18650CP-1900 | 1900 | 3.7 | 18.05 | 64.5 | 10C 15C 20C |
| 10 | Lithium Cylindrical | 18650CP-2000 | 2000 | 3.7 | 18.05 | 64.5 | 10C 15C 20C |
| 11 | Lithium Cylindrical | 18650CP-2100 | 2100 | 3.7 | 18.05 | 64.5 | 10C 15C 20C |
| 12 | Lithium Cylindrical | 18650CP-2200 | 2200 | 3.7 | 18.05 | 64.5 | 10C 15C 20C |
For more info please contact me freely, wish 13years experience in battery area can help you out
in your project.
