3.2V 100Ah Lithium LiFePO4 Battery Long Cycle Life For EV Car Power Station
3.2V 100Ah Lithium LiFePO4 Battery Long Cycle Life For EV Car Power Station
Basic Properties
Place of Origin:
MADE IN CHINA
Brand Name:
/OEM
Certification:
UL CB KC PSE
Model Number:
LF100LA
Trading Properties
Minimum Order Quantity:
50pcs
Price:
negociatable
Payment Terms:
L/C, T/T, Western Union
Supply Ability:
50000pcs/day
Product Summary
LiFePo4 Battery 3.2V 100Ah WITH UL CE IEC CB MSDS CERTIFICATION Long cycle life design with more than 2 years High discharge rate design with stable performance 80Ah,100Ah, 105Ah,173Ah, 280Ah, 230Ah, 304Ah 3.2V cells are available Accept cutomized lifepo4 battery pack with BMS system MSDS UN38.3 IEC ...
Product Custom Attributes
Highlight
100Ah Lithium LiFePO4 Battery
,Power Station Lithium LiFePO4 Battery
Material:
Lithium LiFEPO4
Capacity:
100Ah
Normal Voltage:
3.2V
SIZE:
Width 130.3±0.3mm T Thickness 36.7±0.5mm H High 200.5±0.5mm
CYCLE LIFE:
2000
N.W:
1985±100（g）
Internal Iedance:
Less Than 0.7mΩ
Self Discharge Rate:
≤ 3 ﹪ Month
Product Description
Detailed Specifications & Features
LiFePo4 Battery 3.2V 100Ah WITH UL CE IEC CB MSDS CERTIFICATION
- Long cycle life design with more than 2 years
- High discharge rate design with stable performance
- 80Ah,100Ah, 105Ah,173Ah, 280Ah, 230Ah, 304Ah 3.2V cells are available
- Accept cutomized lifepo4 battery pack with BMS system
- MSDS UN38.3 IEC CB certificate can be available for safety delivery
- Air delviery sea deliver and door to door courier service available
LF100LA 3.2V LIFePo4 Battery Cell Specification:
| NO | ITEM | PARAMETER | NOTE | |
| 1 | nominal capacity | 100Ah | (25+/2)℃,standard charge&a;discharge | |
| 2 | nominal voltage | 3.2V | ||
| 3 | inner resistance(1kHz) | ≦0.5mΏ | ||
| 4 | standard charge and discharge | charge/discharge current | 0.5C/0.5C | (25+/2)℃ |
| charge/discharge cut off voltage | 3.65V/2.5V | |||
| 5 | max charge/discharge currency | continuous charge/discharge | 1C/1C | Reference continuous/pulse ammeter |
| pulse charge/discharge(30s) | 2C/2C | |||
| 6 | Recommended window for SOC | 10%-90% | N.A. | |
| 7 | charging working teerature | 0℃-55℃ | Reference continuous/pulse ammeter | |
| 8 | discharge working teeratue | -20℃-55℃ | ||
| 9 | storage teerature | short period | -20℃-45℃ | N.A. |
| long period | 0℃-35℃ | |||
| 10 | Storage humidity | <95% | ||
| 11 | monthly discharge rate | ≦3%/m | (25+/2)℃,30%-50% SOC storage | |
The size of the liFePO4 battery cell:
Advantage of the cell:
1.High safety performance
2.High dicharge platform, Long Cycle Life:
3. Can offer OEM pack service:
LiFePO4 90Ah Battery are widely used for many senario:
The similar mode we have 32Ah, 80AH,90Ah,105Ah,173Ah, 230Ah, 280Ah,
for more please contact me freely. Wish my 15year experience in battery area can help you out.
